CAS Power Supply Auto FR E 100~240VACS 12VDC 1000MA P4
More information about Power Supplies by clicking on “Contact Us” and downloading the PDF with the technical specifications.
Related Products:
Power Supply
12W
ref. 132.0024.00
CAS Power Supply Auto FR E 100~240VACS 12VDC 1000MA P4
Power Supply
12W
ref. 132.0024.00
More information about Power Supplies by clicking on “Contact Us” and downloading the PDF with the technical specifications.
Related Products:
Technical Specification
- Source Type: External
- Connector A: Standard NBR Plug 14136:2002 – Input Power
- Connector B: P4 (DC5,5×2,1mm) – Output CC Power
- Input Voltage: 100~240VCA (F+N)
- Output Voltage: +12VCC
- Output Power: 12W
- Output Voltage Precision: +/-2%
- Input Frequency: 50~60Hz
- Input Filter: Modo comum
- Protection against Short Circuit and Overload: Yes
- Dimensions: 73 x 66 x 36mm
- Weight: 155g
Technical Drawing
